Measure frequencies and provide analog output for deployment in many applications
Item number IFM0001
The IFM Universal Frequency to Analog Converter/Speed Switch is a high-performing signal conditioner that offers unmatched frequency transmission capability. Detachable programming window makes it easy to program and recalibrate the device, as well as mirror existing configurations to save time.
Measures frequency inputs (NPN, PNP, Tacho, & TTL) from 1 Hz to 100 KHz.
2.3 kVAC, 3-port galvanic isolation. All terminals are over-voltage protected (24 VDC), polarity protected and short-circuit protected.
Programmable bipolar mA / V or relay. Provides an analog output proportional to the input signal.
Active and passive current output ±23 mA / 0 to 23 mA.
Buffered voltage output ±10 VDC.
Provides over-speed, under-speed or zero-speed detection. Output relay with windows, setpoint and latch functionality.
Easy to configure using the detachable programming display module (PGMMOD). Save time by programming one unit and downloading the configuration to others.
Units can be mounted side by side, horizontally and vertically, without air gap on a standard DIN rail – even at 60 °C ambient temperature.
Engineered to deliver uncompromising performance in demanding environments.
UL-listed approval.
Universal power supply with 21.6 to 253 VAC and 19.2 to 300 VDCs.
