Monitor and control remote devices easily and intuitively with Graphite® data acquisition modules.
Item number GMTC8000
The Graphite thermocouple analog input module easily connects any device or sensor to Graphite HMIs and can be used in conjunction with any Graphite modules. This high density temperature input module provides up to eight isolated inputs and accepts a wide range of thermocouple types. Ideal for data acquisition applications.
Eight single-ended thermocouple analog inputs for T, E, J, K, R, S, B, N, C types. Includes NIST conformity, cold junction effect, A/D converstion errors, temperature coefficient and linearization conformity. Inputs are isolated from each other and the power supply.
Sample time of 50-400 msec depending on enabled inputs. Temperature coefficient of 0.01%/°C. Unused inputs can be disabled to increase overal reading rate.
Once programmed, the module can operate/control independent of the Graphite device as long as power is applied. Use in conjunction with any Graphite series module.
Retain all programmable parameters.
Modules connect and communicate via proprietary USB connection to the various Graphite devices.
Configure and perform routine re-calibrations with Windows® compatible Crimson® configuration software. The user-friendly graphical interface makes programming quick and easy.
Status LED displays the state of the module, including startup routine and error states. Alarm LED indicates the presence of an input fault condition.
Durable metal construction. Suitable for hazardous environments with UL Class I, Division 2 listing and CE, ATEX/UKEX and IECEx approved. ABS Type approval for shipboard applications. Operating temperature of -40 °C to 75 °C
Power is supplied by the Graphite® host device. Maximum power: 1.4 W.
