Connect additional RS-232/RS-485 communication capability to your FlexEdge devices

DA Series FlexEdge Mixed Isolated RS-232/RS-485 Ports Sled

Item number DAS00PN2245IS000

The FlexEdge Mixed RS-232/RS-485 Ports Sled avoids costly rip-and-replace scenarios. Built for harsh industrial settings and installs easily into your DA50 or DA70 device. RS-232/RS-485 communications sled powered and controled by your FlexEdge device.

Features and benefits

  • Additional RS-232/RS-485 capability for your DA device

    One RS-232 port (RJ12 connector) and one RS-485/RS-422 port (RJ45 connector).

  • Individually isolated ports

    Individual isolation from network to controller: up to 5000 Vrms

  • Configured using Crimson® software

    Programmed with industry leading Crimson® configuration software (version 3.2 or later). Easy to use with low/no code graphical user interface.

  • LED status monitoring

    Each port has a pair of LEDs to indicate transmit and receive activity.

  • Designed for harsh industrial environments

    Engineered to deliver uncompromising performance in demanding environments. Operating temperature of -40 °C to 75 °C.

  • Leading industry certifications

    CE, ATEX, IECEx, UKEX and Class 1, Division 2 approvals for hazardous locations. ABS type approval for shipboard applications.

  • Power supplied by FlexEdge host controller

    Maximum power is 1.5 W.
