Intelligent CAN-to-CAN bridge with CAN FD support

Ixxat CANbridge NT 420

Item number 1.01.0331.42000

The Ixxat CANbridge NT 420 is a configurable CAN to CAN bridge/router to connect different CAN/CAN FD systems. It offers four CAN channels, thereof two CAN FD capable, and supports long-distance communication, with several message processing and multiplexing functionalities. Ideal for efficient network management and system expansion.

Features and benefits

  • Three operation modes in one device

    The Ixxat CANbridge NT can be used as PC interface, as CAN-Ethernet-CAN bridge or as CAN Ethernet gateway – all in one device.

  • Bridge operation enables CAN system expansion

    The bridge mode enables easy message exchange between CAN/CAN FD systems – to setup tree or star topologies.

  • For CAN and CAN FD

    Four independent CAN channels, two of which can be switched via software to CAN FD.

  • Cost savings due to simple wiring

    Optimized topologies enable simpler wiring, resulting in less cables and cost savings at installation and maintenance.

  • On device intelligence

    Advanced filter, ID translation, data mapping and multiplexing functionalities streamline network traffic and enhance efficiency.

  • Customizable actions

    Additional programming of action rules using LUA for tailored responses to specific network events.

  • Device and system protection

    Network segmentation with galvanic isolation protects devices against damage caused by voltage peaks.

  • Configurable security levels

    Defined assess levels for configuration or firmware upload.

  • Easy configuration and maintenance

    Windows configuration tool allows for easy setup and maintenance via USB.
